Overview

An Integrated Post-Silicon Validation and ATMP Hub

Silicon that passes simulation can still fail in the real world. Process variation, thermal stress and reliability issues only surface once the chip is fabricated.

HCLTech's Advanced Semiconductor Lab (ASL) brings end-to-end post-silicon validation, testing and ATMP (Assembly, Test, Mark, Pack) into a single, integrated environment, so those issues are caught before high-volume production. Designed to support the complete silicon lifecycle, the lab enables a seamless transition from validation through characterization, qualification, failure analysis and system-level testing.

With advanced ISO 6 (Class 1K) and ISO 7 (Class 10K) cleanroom infrastructure, Our ASL delivers wafer and package-level testing, reliability qualification, electrical and RF characterization and advanced diagnostics — combining deep domain expertise with advanced test and analysis workflows to help semiconductor, automotive and industrial customers achieve faster time-to-market, reduced risk and improved yield.

Section CTA

Key Highlights

Section CTA

40,000 sq. ft. of advanced engineering infrastructure

Expansive engineering infrastructure

25,000 sq. ft. of Class 10K and 1K cleanrooms

Precision cleanroom environments

End-to-end post-silicon coverage

Comprehensive post-silicon solutions

World-class infrastructure and advanced engineering

Premier engineering ecosystem

Accelerating precision chip engineering and innovation

Driving precision and innovation

Industry-grade compliance and certifications

Certified for industry excellence

Designed for faster turnaround and time-to-market

Faster time-to-market enablement

Scalable, secure and high-performance operations

Scalable and high-performance operations

Post-Silicon Validation, Testing and Failure Analysis Services

In the race from silicon to system readiness, the real differentiator isn't design — it's how quickly and confidently silicon performs in the real world. Fragmented, multi-vendor test flows add handoffs, schedule slips and risk. Our ASL is designed to power this critical transformation—serving as a catalyst to accelerate post-silicon engineering, improve yield and enable reliable, scalable productization.

Silicon validation and characterization

Functional, electrical, parametric, RF, power and performance testing across wafer and package-level characterization

ATE engineering and testing

Test program development and debug, wafer sort and final test and high-throughput production testing

Device qualification and reliability

ESD, latch-up, HTOL, HAST, temperature stress testing and automotive and industrial qualification flows

Failure analysis and debug

Physical and electrical failure analysis, advanced microscopy and circuit editing capabilities

Packaging and ATMP/SMT assembly

High-precision solder paste printing, pick-and-place, reflow with vacuum and inline inspection with AOI

Why HCLTech ASL: From Silicon Validation to Market Readiness

Accelerating Silicon Confidence: From Validation to Market Readiness

When semiconductor programs are impacted by multiple handoffs, delayed decision cycles and increasing compliance requirements, innovation can slow and costs can rise. Our ASL helps overcome these challenges through a single-site engineering environment that combines advanced testing, validation, qualification and failure analysis capabilities. Supported by world-class infrastructure and specialized engineering expertise, our ASL delivers faster innovation, stronger quality assurance and scalable semiconductor outcomes across the product lifecycle.

Section CTA

Integrated single-site execution

End-to-end validation, testing, qualification and failure analysis within one ecosystem—reducing handoffs and increasing engineering continuity

Faster decision cycles

Co-located capabilities enable quicker debugging, validation and production readiness—driving faster time-to-market

Scalable infrastructure

Built for high-complexity, high-volume semiconductor programs across industries

ISO/IEC 17025 alignment

Advanced infrastructure aligned to global quality standards and industry-grade certifications, ensuring reliability and compliance

Strategic lifecycle value

Supports R&D, pre-production and production programs—enabling better yields and more predictable productization

Ecosystem advantage

Backed by specialized engineering talent, academia collaboration and cross-industry partnerships enabling faster problem-solving, innovation at scale and future-ready silicon development

What We Test and How

Choosing an outsourced validation partner means knowing exactly what gets tested and how. Our ASL covers the full post-silicon scope:

All work runs in ISO 6 (Class 1K) and ISO 7 (Class 10K) cleanrooms, aligned to ISO/IEC 17025.

Section CTA

Characterization

Functional, electrical, parametric and RF measurement across process, voltage and temperature to define real-world operating limits

Reliability and qualification

HTOL, HAST, ESD, latch-up and temperature stress testing to predict long-term field reliability and meet automotive and industrial qualification flows

ATE engineering

Test program development, wafer sort and final test for high-throughput production

Failure analysis

Physical and electrical fault isolation, advanced microscopy and circuit editing to find root cause fast

ATMP

Assembly, Test, Mark and Pack, packaging fabricated dies for shipment in the same integrated environment

Section Title
Case Studies

Explore Real-World Impact Delivered

Partner with Us

Co-Create Your Next Silicon Breakthrough
From post-silicon validation to production readiness, engage with us to accelerate innovation and achieve silicon confidence.
